Introduction:
YGM high pressure micro powder mill is referred to as micro powder mill or super fine grinding mill. The high-pressure micro grinder is mainly used for the ultra-fine powder processing of more than 500 kinds of materials such as feldspar talc barite marble limestone carbon black and clay. It’s widely used in the mining, metallic minerals, Recycled Aggregate, and construction industries.
Advantages:
● Newly designed grinding curves of grinding roller and grinding ring further enhance the grinding efficiency of HGM Ultrafine Grinding Mill.
● With the same fineness and power the production capacity is 40% higher than that of jet grinding mill and stirred grinding mill.
● The yield is twice as large as that of ball grinding mill. However, the system energy consumption is only 30% of the jet grinding mill.
Technical Parameters:
Model | Ring Diameter (mm) | Rollers Diameter (mm) | Speed of Main Mill
(r/min) | Max Feeding Size (mm) | Final Size
(mesh) | Capacity
(t/h) | Dimension(mm) |
YGM1100-Q4 | φ1100 | φ320×170 | 132 | ≤25 | 80-800 | 0.5-6.5 | 7350×5900×7900 |
YGM1400-Q4 | φ1400 | φ430×210 | 106 | ≤30 | 80-600 | 2-13.8 | 8000×8550×9700 |
YGM1500-Q4 | φ1500 | φ460×230 | 105 | ≤30 | 80-600 | 2.9-17.5 | 9700×8500×10200 |
YGM1750-Q4 | φ1750 | φ520×270 | 92 | ≤30 | 80-425 | 5-25 | 9230×10116×10510 |
YGM2000-Q4 | φ2000 | φ600×300 | 78 | ≤35 | 80-425 | 6.5-32 | 9368×11500×11000 |
YGM2200-Q4 | φ2200 | φ630×320 | 72 | ≤35 | 80-425 | 8.4-40 | 10465×11372×11500 |
Power Specification:
Model | Main
Mill Power
( kW) | Power of
Air Blower
(kW) | Power
of Classifier
(kW) | Model of Pulse Dust Collector | Dust Collector (kw)Blower+
Air Compressor | Power of
Frequency feeder (kW) |
YGM1100-Q4 | 37 | 30- 37 | 5.5- 11 | DMC36 | 3+4 | 0.15 |
YGM1400-Q4 | 75- 90 | 75- 90 | 18.5- 22 | DMC36 | 3+4 | 3 |
YGM1500-Q4 | 90- 110 | 110- 132 | 22- 30 | DMC48 | 3+4 | 4 |
YGM1750-Q4 | 132- 160 | 160- 200 | 30- 37 | DMC64 | 5.5+5.5 | 5.5 |
YGM2000-Q4 | 185- 200 | 200- 220 | 37- 45 | DMC96 | 7.5+7.5 | 5.5 |
YGM2200-Q4 | 220- 250 | 220- 250 | 45- 55 | DMC96 | 7.5+7.5 | 5.5 |
