Introduction：
YA and YK Series Circular Vibrating Screens are specifically designed for screening mineral stones at the working site.
This series feature of various models, novel structure, strong exciting force, large processing capacity, high screening ratio, little vibrating noise, completely new design, state-of-the-art manufacturing; all these features make this screen durable and easy for maintenance. This screen has been widely used in construction, transportation, energy, cement, mining and chemical industries.
Features：
Strong in vibration and powerful in processing capability;
High in efficiency and small in vibrating noise;
Durable in construction and easy in maintenance;
Technical Parameters：
Model | Layer of Screen | Size of Sieve Pore (mm) | Max.
Feeding Size (mm) | Capacity
(m³/h) | Double Amplitude (mm) | Motor Power
(kW) |
2YA1548 | 2 | 3~100 | 300 | 22~160 | 8 | 15 |
3YA1548 | 3 | 3~100 | 300 | 22~160 | 8 | 15 |
4YA1548 | 4 | 3~100 | 300 | 22~160 | 8 | 15 |
2YA1848 | 2 | 3~100 | 300 | 32~276 | 8 | 18.5 |
3YA1848 | 3 | 3~100 | 300 | 32~276 | 8 | 18.5 |
4YA1848 | 4 | 3~100 | 300 | 32~276 | 8 | 18.5 |
2YA1860 | 2 | 3~100 | 300 | 65~586 | 8 | 22 |
3YA1860 | 3 | 3~100 | 300 | 65~586 | 8 | 22 |
4YA1860 | 4 | 3~100 | 300 | 65~586 | 8 | 22 |
2YA2160 | 2 | 3~100 | 300 | 81~720 | 8 | 30 |
3YA2160 | 3 | 3~100 | 300 | 81~720 | 8 | 30 |
4YA2160 | 4 | 3~100 | 300 | 81~720 | 8 | 37 |
2YA2460 | 2 | 3~150 | 300 | 90~810 | 8 | 37 |
3YA2460 | 3 | 3~150 | 300 | 90~810 | 8 | 37 |
4YA2460 | 4 | 3~150 | 300 | 90~810 | 8 | 37 |
3YK3072 | 3 | 3~200 | 300 | 180~1300 | 8 | 30×2 |
3YK3072 | 3 | 3~200 | 300 | 180~1300 | 8 | 30×2 |
