Single Cylinder Cone Crusher Jiaxing Gypmach Machinery Co., Ltd

Single Cylinder Cone Crusher

Introduction:

The single cylinder hydraulic cone crusher is widely used in mining, metallurgy, building materials, highway, railway, water conservancy, chemical industry, etc. It is widely used in secondary crushing of limestone, granite, gabbro, basalt, river stone, coal gangue, quartz, diabase, iron ore, cooper ore, zinc ore, manganese ore, with medium hardness and above. The single cylinder hydraulic cone crusher has features of simple structure, stable and reliable operation, easy maintenance. It is the ideal crusher machine for middle crushing or fine crushing of rocks or minerals.

Advantages:

1> Large crushing ratio and high production efficiency;

2> Laminated crushing, more uniform finished products;

3> Low consumption of wearing parts and low operating costs;

4> The advanced hydraulic technology realizes the overload protection and hydraulic adjustment discharge outlet, which simplifies the crusher structure and reduces the weight;

5> Thin oil lubrication is reliable and advanced, which can increase the service life of the crusher;

6> Easy maintenance, easy to operate.

Technical Parameters:

Model	Power (kW)	Cavity Type	Max Feeding Size (mm)	Throughput (t/h) if Crusher Running at CSS (mm)
GMH820	90			6	8	10	13	16	19	22	25	32	38	44	51
		EC	135			55	100	105	115	120	130	145
		C	90			60	405	110	120	125	135	80
		M	65		50	85	90	90	70
		MF	50	40	75	80	80	60
		F	38	60	60	65	55	45
		EF	28	30-40t/h with 80% less than 4.5-5.5mm
				6	8	10	13	16	19	22	25	32	38	44	51
		EC	190				125	170	185	196	210	240	240
		C	145			85	150	165	175	185	200	225	170
GMH830	160	MC	115			65	160	175	185	200	210	165
		M	90		75	100	150	165	175	185	175	120
		MF	75		70	120	130	145	145	130	105
		F	50	90	95	100	110	120	120	110	90
		EF	35	70-90t/h with 80% less than 5-5.6mm
				6	8	10	13	16	19	22	25	32	38	44	51
		EC	215					200	276	294	313	357	395	384
		C	175				101	218	292	312	332	378	335	229
GMH840	250	MC	140				122	262	282	301	320	328	242
		M	110				187	278	298	318	339	281	194
		MF	85			114	227	245	263	281	299	248
		F	70		135	176	191	206	221	236	251	208
		EF	38	100-125t/h with 80% less than 6-7.5mm
				6	8	10	13	16	19	22	25	32	38	44	51
		EC	275					177	338	436	464	547	605	662	511
		C	215					190	367	480	501	582	643	512	353
GMH860	315	MC	175					253	426	455	484	552	499	364
		M	135					295	440	470	500	502	403
		MF	115				192	369	396	423	450	451	363
		F	85				304	328	352	376	400	401	323
		EF	65				293	316	298	290
				13	16	19	22	25	32	38	44	51	57	64	70
		EC	300				588	849	968	1070	1172	1291	1393	1512	1331
		C	240			406	636	893	1018	1125	1232	1357	1464	1461	1286
GMH870	500	MC	195			440	723	837	954	1055	1155	1272	1373	1370	1206
		M	155			563	786	836	953	1054	1154	1271	1372	1248	1098
		MF	100		424	716	765	814	928	942	789	702
		F	120	289	669	838	895	952	1085	1165	1051	827	625
				10	13	16	19	22	25	32	38	44	51	57	64
GMH885	750	EFX	100		423	666	715	763	812	926	994	896	705	533
		EF	85	246	585	631	678	724	770	878	970	1063	1170	1010	862
		EEF	75	475	564	608	653	697	742	846	855	761	580	417

Model	Power (kW)	Cavity Type	Max Feeding Size (mm)	Nominal capacity in t/h with crusher running at CSS （mm）
				16	19	22	25	29	32	35	38	41	44	48	51
GMS820	90	EC	240			110	123	142	151	145	132
GMS820	90	C	200	77	85	105	110	131	133
GMS830	160	EC	360				151	161	175	193	243	285	300	281	250
GMS830	160	C	300				170	182	203	256	273	295	305	237
GMS840	250	EC	450							273	323	345	356	421	447
GMS840	250	C	400						291	335	363	395	415	421	375
GMS860	315	EC	560								385	464	535	621	647
GMS860	315	C	500							335	418	535	620	660	683
