Introduction:
The jigging machine is widely used in the beneficiation of non-metal mineral, metal mineral and smelting slag. The processing material is as following:
Non-metal mineral: Barite ore, fluorite ore, garnet ore, celestite
Metal mineral: Manganese ore, antomy ore, chromite ore, tin ore, lead ore, scheelite ore, wolframite, iron ore, copper ore
Precious mineral: Gold, diamond, zircon ore, tantalite ore, columbite ore
Advantages:
1. Energy-saving, high enrichment efficiency and environmental-friendly.
2. Trapezoid Working area, high recovery rate, and large handling capacity.
3. Eight jig dressing chambers, adjustable stroke and stroke frequency for each slot, wide range of selected particle size.
4. High stability, simple operation, convenient maintenance
Technical Data of AM30:
Model | Section Form | Column
Quantity | Jigging
Chamber
No. | Jigging Area
(㎡) | Stroke
Coefficient | Stroke
(mm) | Stroke
Frequency
(times/min) | Handling
Capacity
(T/h) | Power
(KW) |
AM-30 | Rectangular | 2 | 4 | 2.574 | 0.47 | 0-50 | 130-160 | 10-15 | 3 |
Technical Data of 2LTC366/8T:
Model | Section
Form | Column
No. | Jigging
Chamber
Qty. | Jigging
Area
(㎡) | Stroke
Coefficient | Stroke
(mm) | Stroke
Frequency
(times/min) | Handling
Capacity
(T/h) | Power
(KW) |
|
|
2LTC366/8T | Trapezoid | 2 | 8 | 2.16 | 0.68-0.41 | 0-50 | 120-300 | 3-6 | 1.1*2 |
2LTC6109/8T | Trapezoid | 2 | 8 | 5.76 | 0.52-0.35 | 0-50 | 120-300 | 20-30 | 1.5*4 |
Technical Data of 2LTC-912/4A:
Model | Section
Form | Column
No. | Jigging
Chamber
Qty. | Jigging
Area
(㎡) | Stroke
Coefficient | Stroke
(mm) | Stroke
Frequency
(times/min) | Handling
Capacity
(T/h) | Power
(KW) |
|
|
2LTC-912/4 | Trapezoid | 2 | 4 | 4.32 | 0.49 | 0-50 | 160-280 | 10-30 | 11 |
2LTC912/4A | Trapezoid | 2 | 4 | 4.32 | 0.49 | 0-100 | 120-160 | 20-40 | 11 |
Technical Data of JT1070/2:
Model | Stroke
Coefficient | Stroke
(mm) | Stroke
Frequency
(times/min) | Feeding size
(mm) | Capacity (t/h) | Water consumption (t/h) | Power
(KW) |
|
|
JT1070/2 | 0.5 | 0-12 | 0-170 | 8 | 6-8 | 5-40 | 3 |
JT1515/2 | 0.47 | 0-25 | 0-150 | 10 | 15-20 | 30-120 | 4*2 |
JT2020/2 | 0.4 | 0-20 | 0-130 | 10 | 25-40 | 60-180 | 7.5*2 |
Technical Data of FRT2/10-6 & FRT2/15-6:
Model | Stroke
Coefficient | Stroke
(mm) | Stroke
Frequency
(times/min) | Feeding size
(mm) | Capacity (t/h) | Water consumption (t/h) | Power
(KW) |
|
|
FRT2/10-6 | 0.5 | 0-70 | 0-200 | 0-8 | 30-40 | 200 | 11 |
FRT2/15-6 | 0.5 | 0-70 | 0-200 | 0-8 | 60-80 | 300 | 22 |
Technical Data of LTP34/2:
Model | Stroke
Coefficient | Stroke
(mm) | Stroke
Frequency
(times/min) | Jigging
Chamber
Qty. | Capacity (t/h) | Power
(KW) |
|
|
LTP34/2 | 0.58 | 0-27 | 280-340 | 2 | 0.5-1 | 1.1 |
