Introduction:
4R3220 Improved pendulum pulverizer is mainly used in chemical and building material industry and such as grinding glass, rubber, pesticides, enamel, paint, phosphate fertilizer, paper. Hardness below seven Moh’s hardness following humidity below 6% non-flammable and explosive materials. Such as: talc, barite, calcite, limestone, marble, manganese ore, iron ore soil, chrome ore, feldspar, quartz, gypsum, kaolin, bentonite, etc.
This machine has the advantages of high output, wide use, power saving, convenient operation and stable performance. It is an ideal equipment for grinding industry.
Technical Parameters:
(1) Main Unit
Max feeding size | 20mm |
Finished product size | 80-400mesh |
Capacity | 1-6t/h |
Rotating speed of central shaft | 140r/min |
Inner diameter of grinding ring | Φ970mm |
Roller dimension (outer diameter*height) | Φ320×200mm |
(2) Classifier
Diameter of classifier rotor | Φ894mm |
(3) Air Blower
Wind volume | 15433-24308m3/h |
|
Wind pressure | 7400-6300 Pa |
|
Rotating speed | 1850 r/min |
|
(4) Whole set
Gross weight | 14t |
Total installed power | 97KW（excluding crusher, bucket elevator） |
Overall dimension after installation(L*W*H) | 7890mm×5023mm×8370mm |
(5) Motor
Installed position | Power（kW） | Rotating speed（r/min） |
Main unit | 45 | 1480 |
Classifier | 37 | 1250 |
Blower | 15 | 1480 |
